Confirm before shipping
We agree the laser power, lens, electrical requirements, accessories, packing and shipping method in your quotation. Delivery time is negotiated for each order.
DRAGON DIAMOND · LASER MARKING SOLUTIONS
LZ-RF CO2 Laser Marking Machine 30W–60W
CO2 RF laser marking with 30W–60W power options for wood, leather, acrylic and other suitable non-metal materials. Select the power and marking lens around your material, artwork and production requirements.
Equipment selection · Free sample testing · Technical support
Marking Samples & Applications
Applications include decorative wood and bamboo items, leather branding, acrylic marking and suitable non-metal gift products. Marking contrast and finish vary by material; free sample testing helps confirm suitability.
Samples illustrate applications, not a guarantee for every material or configuration. Send your material and artwork for a free sample test.
Request a Free Sample TestCO2 RF laser marking with 30W–60W power options for wood, leather, acrylic and other suitable non-metal materials. Select the power and marking lens around your material, artwork and production requirements.
Product Features
- CO2 RF laser power options from 30W to 60W, selected for your application.
- 10.6 μm wavelength for non-metal marking applications.
- Air cooling and an integrated desktop machine layout.
- Galvanometer scanning and EZCAD marking software.
Configuration & Customization
Choose a CO2 RF laser configuration from 30W to 60W according to your material, marking size and production requirements. Confirm the laser source, lens, working field and cooling arrangement in your quotation. The reference 35W configuration uses a DAVI source; specifications may differ with the selected power.
Applications & Material Selection
Applications include decorative wood and bamboo items, leather branding, acrylic marking and suitable non-metal gift products. Marking contrast and finish vary by material; free sample testing helps confirm suitability.
Technical Specifications
View technical specifications
| Laser power options | 30W–60W |
|---|---|
| Model | LZ-RF |
| Laser source | CO2 RF; source confirmed with selected power |
| Wavelength | 10.6 μm |
| Marking area | 110 × 110 mm listed as optional; confirm lens configuration |
| Control software | EZCAD |
| Cooling | Air cooled |
| Listed maximum marking speed | 2,000 mm/s; actual cycle time depends on the job |
| Electrical supply | AC 220V / 50Hz |
| Rated power consumption | <500W |
| Machine dimensions | 750 × 480 × 600 mm |
| Machine weight | 50 kg |
Cooling, electrical supply, consumption, dimensions, weight and speed above refer to the original 35W reference configuration. Specifications for other power options are confirmed in your quotation. Values depend on the selected configuration and operating conditions. Confirm the final specification and required marking result before ordering.
Order-specific Packaging
Packing dimensions, gross weight and shipping method are confirmed with the selected configuration and destination before dispatch.
Packaging, Delivery & Technical Support
Installation & training
English manuals and videos support setup and operation. Our technical team provides remote training and assistance with day-to-day use. On-site training and technical support can be arranged by agreement.
Spare parts & equipment planning
We prepare corresponding spare parts for each machine and help plan compatible equipment for your production workflow.
Frequently Asked Questions
How do I choose the right laser marking machine?
Start with your material, coating, marking area, required contrast and production volume. Compare Fiber, CO2 and UV options, then confirm the result with a sample test.
Can you test my material before I order?
Yes. We provide free sample testing to check the proposed configuration. Send your artwork and material information using the inquiry form; sample shipping arrangements are agreed separately.
Can the configuration be customized?
We help select the listed power and lens options. Tell us your workpiece dimensions, electrical supply and any rotary marking requirements so we can confirm a compatible configuration.
What is the price and delivery time?
We quote according to the selected configuration, accessories and delivery requirements. Lead time is confirmed for your specific order.
Compare Laser Marking Machines
Get a Quote for Your Marking Application
Tell us your material, workpiece size, artwork and production requirements.
